Crown Industries BWR Plywood is made from quality wood and undergoes superior quality phenol bonding to confirm to IS: 303 standard. It is dimensionally stable and durable for lasting services. Bonded with high quality Phenol Formaldehyde Resin it is pressed under heat, pressure and controlled conditions to obtain a BWP bond, which is highly resistant to cold and boiling water. Most insects when attack a wood based panel, bore into the core for food. The core of Golden contains certain complex chemicals which make it termite and borer proof.
It is the most ideal material for use in furniture and Fixtures, kitchens, Bathrooms, Booths, Cupboards, Doors, Partitions, Shelves, Bus and truck bodies, Railway coaches and almost anything that can be thought of in plywood. You can, therefore, be assured of a life time trouble free performance.
| Test | ISI Requirement | Test Result | ||
|---|---|---|---|---|
| Moisture Contents | 5-15% | 7-10% | ||
| Dimension & Squareness |
|
|
||
| MOR | Avg. | Min. Ind. | Avg. | Min. Ind. |
| N/mm2 | N/mm2 | N/mm2 | N/mm2 | |
| Along the grain | 40 | 36 | 45 | 21 |
| Across the grain | 20 | 18 | 22 | 21 |
| MOE | Avg. | Min. Ind. | Avg. | Min. Ind. |
| N/mm2 | N/mm2 | N/mm2 | N/mm2 | |
| Along the grain | 5000 | 4500 | 5500 | 5100 |
| Across the grain | 2500 | 2200 | 3000 | 2600 |
| Water Resistance Test | No de-lamination in three cycles of dipping in boiling water for 8 hours followed by drying at temperature of 65±2°C for 16 hours in each cycle | can undergo four cycles without any de-lamination | ||
